Machuca Fittings, based in Kuala Lumpur, Malaysia, stands out as a top-notch manufacturer and supplier of high-quality pipe fittings tailored for a variety of industrial sectors. One of their standout products, the 90 Deg Long Radius Elbow, is meticulously designed to facilitate smooth fluid flow and directional shifts within piping systems. Renowned for its sturdy construction and exceptional quality, this elbow is built to comply with rigorous industry standards. Machuca Fittings prioritizes reliability, durability, and customer satisfaction, making it a go-to choice for industries like oil and gas, water treatment, and chemical processing, all while providing solutions that boost operational efficiency and safety.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 90° Long Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 90° Long Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 90° Long Radius Elbow
Typically crafted from carbon steel, stainless steel, or alloy materials, the 90 Deg Long Radius Elbow is tailored to meet the specific requirements of each application. It boasts impressive tensile strength, hardness, and resistance to corrosion, ensuring it lasts even in tough environments. The long radius design enhances flow dynamics by minimizing turbulence and pressure drops, making it perfect for high-pressure and high-temperature scenarios. Manufactured in line with ASTM, ASME, or API standards, this elbow guarantees structural integrity and performance, delivering consistent quality that meets the needs of critical industrial applications.
Stainless Steel 90° Long Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 90° Long Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 90° Long Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 90° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 90° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 90° Long Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 90° Long Radius Elbow : ASTM A420 WPL3, A420 WPL6
Machuca Fittings is a leading supplier of 90 Deg Long Redius Elbow in Kuala lumpur, Malaysia. We offer an extensive range of 90 Deg Long Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 90 Deg Long Redius Elbow from Machuca Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
90° Long Radius Elbows offer several advantages, including smooth directional changes in piping systems that minimize turbulence and reduce pressure loss. The long radius design ensures a more gradual bend, which helps maintain flow efficiency and reduces the likelihood of erosion or wear on the pipe. Made from durable materials like stainless steel and alloys, these elbows provide excellent resistance to corrosion and high-pressure environments. They are ideal for industries such as oil and gas, chemical processing, and water treatment, ensuring long-term reliability, durability, and enhanced system performance.
Yes, custom sizes for 90 Deg Long Redius Elbow are available at Machuca Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@machucafittings.com.
| LONG RADIUS ELBOWS (R = 1,5 ND) ANSI B 16.9 dimensions | ||||||
| inches | ND | mm | Center to center | Radius | Center to end | Back to face |
| D | O | A | B | K | ||
| 1/2 | 15 | 21,34 | 76,20 | 38,10 | 15,87 | 47,62 |
| 3/4 | 20 | 26,67 | 57,15 | 28,57 | 11,11 | 42,86 |
| 1 | 25 | 33,40 | 76,20 | 38,10 | 22,22 | 55,56 |
| 1 1/4 | 32 | 42,16 | 95,25 | 47,60 | 25,40 | 69,85 |
| 1 1/2 | 40 | 48,26 | 114,30 | 57,15 | 28,57 | 82,55 |
| 2 | 50 | 60,32 | 152,40 | 76,20 | 34,92 | 106,40 |
| 2 1/2 | 65 | 73,02 | 190,50 | 95,25 | 44,45 | 131,80 |
| 3 | 80 | 88,90 | 228,60 | 114,30 | 50,80 | 158,75 |
| 3 1/2 | 90 | 101,60 | 266,70 | 133,35 | 57,15 | 184,15 |
| 4 | 100 | 114,30 | 304,80 | 152,40 | 63,50 | 209,55 |
| 5 | 125 | 141,30 | 381,00 | 190,50 | 79,38 | 261,90 |
| 6 | 150 | 168,27 | 457,20 | 228,60 | 95,25 | 312,70 |
| 8 | 200 | 219,07 | 609,60 | 304,80 | 127,00 | 414,30 |
| 10 | 250 | 273,05 | 762,00 | 381,00 | 158,75 | 517,50 |
| 12 | 300 | 323,85 | 914,40 | 457,20 | 190,50 | 619,10 |
| 14 | 350 | 355,60 | 1066,80 | 533,40 | 222,25 | 711,20 |
| 16 | 400 | 406,40 | 1219,20 | 609,60 | 254,00 | 812,80 |
| 18 | 450 | 457,20 | 1371,60 | 685,80 | 285,74 | 914,40 |
| 20 | 500 | 508,00 | 1524,00 | 762,00 | 317,50 | 1016,00 |
| 22 | 550 | 558,80 | 1676,40 | 838,20 | 342,90 | 1117,60 |
| 24 | 600 | 609,60 | 1828,80 | 914,40 | 381,00 | 1219,20 |
| 28 | 700 | 711,20 | 2133,60 | 1066,80 | 441,90 | 1422,40 |
| Dimensions in mm. | ||||||
The 90 Deg Long Radius Elbow finds its place in industries where smooth directional changes are crucial for effective fluid management. It’s commonly utilized in oil and gas pipelines, chemical plants, power generation facilities, and water treatment systems. Its capability to handle high-velocity fluids while minimizing pressure loss makes it ideal for HVAC systems, shipbuilding, and marine engineering. Thanks to its robust construction, it can endure corrosive and high-pressure conditions, ensuring long-term reliability. Consequently, it plays a key role in maintaining efficient, safe, and cost-effective operations across a wide range of industrial processes.
