Machuca Fittings, based in Kuala lumpur, Malaysia, is a renowned manufacturer and supplier specializing in high-quality piping solutions. We offer an extensive range of fittings, including Long Radius and Piggable Bends, designed for efficient flow control and seamless integration in various industrial applications. Our products are crafted using premium materials to ensure durability, reliability, and easy maintenance, making them ideal for complex piping systems across sectors like oil, gas, and construction.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Size: 1/2″–60″
Form: Long Radius Bend, Induction Bend, With R=3D, 5D, 6D, 8D, 10D & Customized Bend
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Size Range : 2″NB TO 18″ NB ANSI B 16.9 IN
Form: Piggable Bends
Long Radius and Piggable Bends are typically made from high-grade materials such as carbon steel, stainless steel, and alloy steel, ensuring strength and durability. The composition often includes elements like carbon, chromium, molybdenum, and nickel, providing resistance to corrosion, heat, and pressure. Mechanically, these bends offer excellent tensile strength, yield strength, and elongation properties, ensuring they can withstand high-pressure systems. With smooth internal surfaces, they allow for optimal fluid flow, while their radius ensures minimal turbulence and pressure loss, making them suitable for complex pipeline networks.
Machuca Fittings is a leading supplier of Long Redius and Piggable Bend in Kuala lumpur, Malaysia. We offer an extensive range of Collar, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Long Redius and Piggable Bend from Machuca Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Long Radius and Piggable Bends offer several key advantages, including smooth internal surfaces that minimize flow turbulence and reduce pressure drops in pipeline systems. Their gentle curves ensure a more efficient flow of fluids, enhancing overall system performance. The durability and resistance to corrosion, heat, and pressure, especially in materials like stainless steel and alloy steel, extend the lifespan of the fittings. Additionally, their ability to accommodate pigs (cleaning tools) ensures easier maintenance and reduces the risk of blockages, making them ideal for complex and demanding piping applications.
Yes, custom sizes for Long Redius and Piggable Bend are available at Machuca Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@machucafittings.com.
Stainless Steel Long Radius Bend : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Long Radius Bend : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel Long Radius Bend : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel Long Radius Bend : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex Long Radius Bend : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy Long Radius Bend : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel Long Radius Bend : ASTM A420 WPL3, A420 WPL6
Stainless Steel Piggable Bend : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Piggable Bend : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel Piggable Bend : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel Piggable Bend : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex Piggable Bend : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy Piggable Bend : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel Piggable Bend : ASTM A420 WPL3, A420 WPL6
| Nominal PN (MPa) | DN | Thread D | Pipe Specification DH×s | L1 | L2 | L3 (Not less than) | L (Not less than) | R |
| 32.0 | 175 | M240×6 | 245×36 | 120 | 130 | 360 | 1095 | 735 |
| 200 | M265×6 | 273×40 | 130 | 140 | 390 | 1209 | 819 | |
| 225 | M320×6 | 325×50 | 175 | 185 | 525 | 1500 | 975 | |
| 250 | M350×6 | 355.6×55 | 195 | 205 | 580 | 1650 | 1070 | |
| 22.0 | 175 | M215×6 | 219×24 | 100 | 110 | 300 | 957 | 657 |
| 200 | M240×6 | 245×26 | 110 | 120 | 330 | 1065 | 735 | |
| 225 | M265×6 | 273×29 | 115 | 125 | 345 | 1164 | 819 | |
| 250 | M295×6 | 299×32 | 120 | 130 | 360 | 1257 | 897 |
Long Radius and Piggable Bends are widely used in industries such as oil and gas, chemical, petrochemical, and water treatment. They facilitate smooth fluid flow in pipelines by minimizing pressure drop and flow turbulence. These bends are essential for systems that require regular cleaning and maintenance, as they accommodate pigs for efficient cleaning and inspection. They are used in high-pressure and high-temperature environments, ensuring optimal performance in transportation and distribution of liquids, gases, and slurries. Their durability makes them suitable for complex pipeline configurations and harsh conditions.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
