Machuca Fittings, based in Kuala Lumpur, Malaysia, stands out as a top manufacturer and supplier of Hastelloy C22 Forged Fittings. They specialize in delivering high-quality, corrosion-resistant solutions tailored for tough industrial applications. Their impressive lineup features forged elbows, tees, couplings, unions, and plugs, all meticulously crafted to guarantee leak-proof connections, robust mechanical strength, and lasting reliability. Hastelloy C22, a unique alloy made of nickel, molybdenum, and chromium with a touch of tungsten, is renowned for its remarkable resistance to a wide range of corrosive environments, including both oxidizing and reducing agents. This makes it a perfect fit for industries like chemical processing, petrochemicals, marine, and power generation.
| C22 Forged Fittings Specifications | ASTM B564/ ASME SB564 |
|---|---|
| Alloy C22 Forged Fittings size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Hastelloy C22 Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Hastelloy C22 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM B564 C22 Hastelloy Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Hastelloy C22 Forged Fittings Thread | NPT, BSPT, BSPP |
| C22 Hastelloy Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Nickel Alloy C22 Forged Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plug |
The composition of Hastelloy C22 Forged Fittings primarily includes nickel, chromium, and molybdenum, along with trace amounts of iron, tungsten, and cobalt. This blend offers outstanding protection against pitting, crevice corrosion, stress corrosion cracking, and oxidation, even across varying temperatures. These fittings are known for their impressive tensile and yield strength, high toughness, and exceptional durability, even in high-pressure, high-temperature, and chemically aggressive settings. Thanks to their good weldability and formability, Hastelloy C22 forged fittings maintain their structural integrity and reliable performance in critical industrial environments.
| Grade | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V | Ni |
| C22 | 0.010 | 12.5 – 14.5 | 0.50 | 0.08 | 2.00 – 6.00 | 0.02 | 0.02 | 2.5 | 20 – 22.5 | 2.5 – 3.5 | 0.35 | Bal |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | Psi – 1,00,000 , MPa – 690 | 45 % |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Hastelloy C22 | N06022 | 2.4602 | – | NiCr21Mo14W | NW 6022 | – | – |
| Standard Code | Standard Name |
| ANSI ASME SB-564 | Forged fittings |
| ANSI ASME B16.11 | Socket-welding and Threaded forged fittings |
| MSS SP-79 | Socket-welding reducing Inserts |
| MSS SP-83 | Class 3000 steel socket-welding and threaded unions |
| MSS SP-95 | Swaged nipples and round plugs |
| MSS SP-97 | SW,TH and BW ends for integrally reinforced forged branch outlet |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hastelloy C22 Forged Fittings from Machuca Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Hastelloy C22 forged fittings offer several advantages, making them ideal for demanding applications. Their superior corrosion resistance protects against pitting, crevice corrosion, and stress corrosion cracking, even in aggressive environments like chlorine and acids. The alloy’s excellent weldability and formability ensure ease of fabrication, while its high strength and durability provide long-term reliability. Additionally, Hastelloy C22 maintains exceptional performance at elevated temperatures, making it suitable for a wide range of industrial applications. These properties make it a top choice for industries requiring highly resistant and durable fittings.
Yes, custom sizes for Hastelloy C22 Forged Fittings are available at Machuca Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@machucafittings.com.
Hastelloy C22 Forged Fittings find their place in industries that require top-notch corrosion resistance and mechanical strength. In chemical processing plants, they are essential for piping systems that handle oxidizing and reducing acids, chlorides, and other harsh chemicals. The petrochemical and refinery sectors rely on them for high-pressure, high-temperature process units. Marine applications benefit from their impressive resistance to seawater and brine corrosion. Power generation facilities use them in heat exchangers, condensers, and other vital high-temperature piping systems. Their blend of durability, corrosion resistance, and mechanical strength makes Hastelloy C22 forged fittings the go-to choice for demanding applications.
