Machuca Fittings, based in Kuala Lumpur, Malaysia, has earned a solid reputation as a reliable manufacturer and supplier of Low Temperature A350 LF2 Forged Fittings. They specialize in providing dependable and long-lasting solutions for essential piping systems. Their product lineup features forged elbows, tees, couplings, unions, and plugs, all crafted to guarantee leak-proof performance, structural integrity, and an extended service life. The ASTM A350 LF2 grade is a low-temperature carbon steel known for its toughness, strength, and excellent weldability, making it perfect for cryogenic and sub-zero applications in the oil and gas, petrochemical, power generation, and marine sectors.
| Forged Fittings Specifications | ASTM A350/ ASME SA350 |
|---|---|
| Low Temperature Carbon steel LF2 Forged Fittings size | 1/8” NB to 4” NB (Socket weld & Screwed-Threaded) |
| Low Temperature Carbon steel LF2 Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Low Temperature Carbon steel Gr LF2 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM A350 Low Temperature Carbon steel LF2 Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Low Temperature Carbon steel LF2 Forged Fittings Thread | NPT, BSPT, BSPP |
| Low Temperature Carbon steel LF2 Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Carbon Gr LF2 Forged Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V |
| A350 LF2 | 0.30 | 0.15–0.30 | 0.60–1.35 | 0.035 | 0.040 | 0.12 | 0.02 | 0.30 | – | 0.08 |
| Grade | Yield Strength, Min (MPa) | Tensile Strength, Min (MPa) | Elongation, min, % |
| A350 LF2 | 250 | 485-655 | 22 |
These Low Temperature A350 LF2 Forged Fittings are primarily made up of carbon, manganese, silicon, phosphorus, and sulfur, along with some trace elements. This unique blend gives them impressive tensile and yield strength, good hardness, and remarkable notch toughness even at sub-zero temperatures. They excel in resisting stress, fatigue, and impact, even under extreme conditions. Thanks to their good weldability, ductility, and machinability, LF2 forged fittings are ideal for fabrication and installation in challenging environments while ensuring long-term mechanical reliability.
| ASTM A350 / A350M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Low Temperature Carbon steel LF2 Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | Low Temperature Carbon steel LF2 fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| Products | Size | |
|---|---|---|
| ASTM A350 Low Temperature Carbon steel LF2 90° Elbow | ASTM A350 Low Temperature Carbon steel LF2 45° Elbow | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| ASTM A350 Low Temperature Carbon steel LF2 Forged Tee | ASTM A350 Low Temperature Carbon steel LF2 Union | |
| ASTM A350 Low Temperature Carbon steel LF2 Forged Cross | ASTM A350 Low Temperature Carbon steel LF2 Insert | |
| ASTM A350 Low Temperature Carbon steel LF2 Screwed Bushing | ASTM A350 Low Temperature Carbon steel LF2 Threaded Pipe Nipple | |
| ASTM A350 Low Temperature Carbon steel LF2 Forged Socket weld Cap | ASTM A350 Low Temperature Carbon steel LF2 Screwed Coupling | |
| ASTM A350 Low Temperature Carbon steel LF2 Forged Plug | ASTM A350 Low Temperature Carbon steel LF2 Street Elbow | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Low Temperature A350 LF2 Forged Fittings offer several advantages, including exceptional toughness and durability in low-temperature environments, ensuring reliable performance in critical applications. Their superior mechanical properties, such as high tensile and yield strength, enhance safety and efficiency under extreme conditions. These fittings provide excellent resistance to impact and corrosion, extending service life even in harsh environments. Precision engineering ensures a perfect fit, reducing the risk of leaks. Widely used in industries like oil and gas, petrochemical, and cryogenics, they ensure robust connections in demanding operations.
Low Temperature A350 LF2 Forged Fittings from Machuca Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Low Temperature A350 LF2 Forged Fittings are available at Machuca Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@machucafittings.com.
In industries where piping systems must function in cryogenic and sub-zero temperatures, Low Temperature A350 LF2 Forged Fittings are widely utilized. In the oil and gas industry, they play a crucial role in LNG processing, storage, and transport pipelines. Petrochemical companies rely on them for low-temperature processing units and pressure vessels. Power generation facilities use them in vital cooling and steam systems, while marine and offshore applications take advantage of their durability in tough climates. The combination of toughness, weldability, and mechanical strength makes A350 LF2 forged fittings essential for low-temperature industrial applications.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
