Machuca Fittings, based in Kuala Lumpur, Malaysia, stands out as a top manufacturer and supplier of ASTM A860 WPHY 70 Pipe Fittings. They specialize in providing robust and high-strength solutions tailored for demanding industrial needs. Their product lineup features elbows, tees, reducers, crosses, and caps, all crafted to ensure leak-proof connections, mechanical strength, and long-lasting reliability. ASTM A860 WPHY 70 is a high-strength wrought carbon steel grade that’s commonly used in moderate to high-pressure piping systems. Thanks to its excellent toughness, weldability, and durability, these fittings are perfect for industries like oil and gas, petrochemical, power generation, and other heavy-duty sectors.
| size | Seamless Fittings: 1/2″ – 10″ Welded Fittings: 1/2″ – 48″ |
|---|---|
| Dimensions | BS4504, ASME B16.28, ASME/ANSI B16.9, MSS-SP-43, BS4504, BS1560, BS10 |
| Thickness | SCH20, SCH 100, SCH30, STD SCH40, SCH10, SCH60, XS, SCH 80, SCH 120, SCH 140, SCH 160, XXS |
| Type | DN15-DN1200 |
| Connection | Welding |
| Elbows Manufacturer | Angle : 1.0D, 22.5 deg, 90 deg, 30deg, 45 deg, 180 deg, 5D, 6D, 1.5D, 2.0D, 2.5D, 3D, 4D, 7D-40D . Standard: ASME B16.9, ASME B16.28, BS, GB, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, ISO |
| Manufacturing process | Press, Push, Forge, Cast, etc. |
| Surface treatment | Sand Rolling, Sand blasting, Sand Blasting |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Origin & Mills | USA, Korean, Japanese, Indian, European, Ukraine, Russian |
| Key markets and industries |
|
| Specialized Manufacturer of | Pipe Bend, Crosses, 45º Elbows, Reducers, Tees, 90º Elbows, Pipe Cap, Stub End |
The composition of ASTM A860 WPHY 70 Pipe Fittings includes carbon, manganese, silicon, molybdenum, and trace elements, which together deliver remarkable mechanical properties. These fittings boast superior tensile and yield strength, impressive hardness, and resistance to impact, making them ideal for high-pressure and high-temperature applications. They also offer good weldability and formability, which simplifies fabrication and ensures reliable installation. With their strong resistance to stress, fatigue, and wear, WPHY 70 pipe fittings promise a long service life and maintain structural integrity even in harsh industrial settings.
|
C |
Mn |
P |
S |
Si |
Ni |
Cr |
Mo |
Cu |
Ti |
V |
Cb |
Al |
|
|
A860 |
0.20 |
1.00-1.45 |
0.03 |
0.01 |
0.15-0.40 |
0.50 |
0.30 |
0.25 |
0.35 |
0.05 |
0.10 |
0.04 |
0.06 |
| Element | Tensile Strength(Min PSI) | Yield Strength (Min PSI) | Elongation(%, in 2in.) |
| WPHY 70 | 82000 PSI | 70000 PSI | 20 % |
Machuca Fittings is a leading supplier of ASTM A860 WPHY 70 Pipe Fittings in Kuala lumpur, Malaysia. We offer an extensive range of ASTM A860 WPHY 70 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose ASTM A860 WPHY 70 Pipe Fittings from Machuca Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
ASTM A860 WPHY 70 Pipe Fittings offer several key advantages, including exceptional strength and durability, with a tensile strength of 760 MPa and yield strength of 520 MPa, making them ideal for high-pressure applications. These fittings are highly resistant to impact, corrosion, and wear, ensuring long-lasting performance in harsh environments. Their excellent toughness makes them suitable for low-temperature and offshore applications. Designed for secure, leak-proof connections, ASTM A860 WPHY 70 fittings reduce maintenance and downtime, providing a reliable and cost-effective solution for critical pipeline systems in industries like oil, gas, and petrochemicals.
Yes, custom sizes for ASTM A860 WPHY 70 Pipe Fittings are available at Machuca Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@machucafittings.com
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
| inch | mm | inch | Length (inch) | Center to End (inch) | Center to End (inch) | Lap Diameter (inch) | Long Length (inch) | Short Length (inch) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
You’ll find ASTM A860 WPHY 70 Pipe Fittings widely used in high-pressure pipeline networks and flow systems. In the oil and gas sector, they’re essential for offshore platforms, refineries, and transmission pipelines. The petrochemical industry relies on them in processing units that handle corrosive fluids and gases under extreme conditions. Power generation facilities utilize them in steam, water, and high-temperature piping systems, while the marine and shipbuilding industries appreciate their durability in challenging environments. The combination of strength, toughness, and reliability makes ASTM A860 WPHY 70 pipe fittings a must-have for critical industrial pipelines.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
