Machuca Fittings, located in Kuala Lumpur, Malaysia, stands out as a top manufacturer and supplier of Carbon Steel P235GH Pipe Fittings, delivering reliable and durable solutions for essential piping systems. Their range includes elbows, reducers, tees, crosses, and caps, all designed for precision, leak-proof connections, and a long lifespan. P235GH is a non-alloy quality steel grade that meets EN 10216 and EN 10253 standards, known for its impressive toughness, solid strength, and excellent weldability. These features make P235GH pipe fittings ideal for use in pressure vessels, boilers, and high-temperature pipelines.
| Size Range | Welded Fittings: 1/2″ – 48″ Seamless Fittings: 1/2″ – 10″ |
|---|---|
| Bending Radius | R=8D, 3D, 10D, 1D, 2D, 5D, 6D or Custom MSS Sp-43 |
| Elbows | Angle : 3D, 4D, 5D, 6D, 1.0D, 1.5D, 2.0D, 2.5D, 7D-40D . Standard: MSS SP-75 JISB2312 JISB2313, ASME B16.9, 22.5 deg, 30deg, 45 deg, 90 deg, DIN2605 JISB2311 BS, 180 deg, GB, ISO |
| Specialized manufacturer of | 90º Elbows, Tee, Stub End, Pipe Cap, Crosses, 45º Elbows, Reducers, Pipe Bend |
| Thickness | SCH 140, SCH 160, SCH10, SCH30, STD SCH40, SCH20, XS, SCH 80, SCH60, SCH 100, SCH 120, XXS |
| Dimensions | ASME/ANSI B16.9, BS4504, ASME B16.28, MSS-SP-43, BS4504, BS1560, BS10 |
| Manufacturing process | Press, Forge, Push, Cast, etc. |
| Origin & Mills | Japanese, Korean, European, Indian, USA, Ukraine, Russian |
| Type | DN15-DN1200 |
| Connection | Welding |
| Test Certificates | Raw Materials Certificate EN 10204/3.1B Third Party Inspection Report, etc |
The Carbon Steel P235GH Pipe Fittings are made up of carbon, manganese, silicon, phosphorus, and sulfur in carefully balanced amounts, which provide high toughness, moderate tensile strength, and dependable performance even at elevated temperatures. This chemical makeup boosts their weldability and machinability, making it easy to fabricate and integrate them into various piping systems. P235GH also shows strong resistance to stress, creep, and deformation, ensuring they remain durable and efficient in tough operating conditions.
| C | Si | Mn | Ni | P | S | Cr | Mo | V | N | Nb | Ti | Al | Cu | – |
| max 0.16 | max 0.35 | 0.6 – 1.2 | max 0.3 | max 0.025 | max 0.015 | max 0.3 | max 0.08 | max 0.02 | max 0.012 | max 0.02 | max 0.03 | max 0.02 | max 0.3 | Cr+Cu+Mo+Ni < 0.7 |
| Nominal thickness (mm): | to 100 | 100 – 150 | 150 – 250 |
| Rm – Tensile strength (MPa) (+N) | 360-480 | 350-480 | 340-480 |
Machuca Fittings is a leading supplier of Carbon Steel P235GH Pipe Fittings in Kuala lumpur, Malaysia. We offer an extensive range of Carbon Steel P235GH Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Carbon Steel P235GH Pipe Fittings from Machuca Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Carbon Steel P235GH pipe fittings offer numerous advantages, including excellent weldability, making them ideal for high-pressure and high-temperature environments. Their strong mechanical properties, such as a yield strength of 235 MPa and tensile strength up to 360 MPa, ensure reliability and durability. These fittings provide excellent corrosion resistance in various industrial applications, ensuring long-lasting performance. Additionally, they are cost-effective compared to other materials, offering a great balance between quality and price. Their versatility allows them to be used in a wide range of industries, including power generation, petrochemical, and HVAC systems.
Yes, custom sizes for Carbon Steel P235GH Pipe Fittings are available at Machuca Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@machucafittings.com
| EU EN | USA – | Germany DIN,WNr | Japan JIS | France AFNOR | England BS | Italy UNI | Belgium NBN | Spain UNE | China GB | Sweden SS | Poland PN | Czechia CSN | Finland SFS | Austria ONORM | Russia GOST | Inter ISO | India IS | |||||||||||||||||||||||||||||||
| P235GH |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Nominal Pipe Size | Outside Diameter | Reducers | ||
|---|---|---|---|---|
|
Reduced from
(inches) |
(mm) |
(inches) |
Reduced to
(inches) |
Concentric & Eccentric Length
(inches) |
|
1/2 |
21.3 |
0.840 |
1/4 |
1 1/2 |
|
3/8 |
1 1/2 |
|||
|
3/4 |
26.7 |
1.050 |
3/8 |
2 |
|
1/2 |
2 |
|||
|
1 |
33.4 |
1.315 |
3/8 |
2 |
|
1/2 |
2 |
|||
|
3/4 |
2 |
|||
|
1 1/4 |
42.2 |
1.660 |
1/2 |
2 |
|
3/4 |
2 |
|||
|
1 |
2 |
|||
|
1 1/2 |
48.3 |
1.900 |
1/2 |
2 1/2 |
|
3/4 |
2 1/2 |
|||
|
1 |
2 1/2 |
|||
|
1 1/4 |
2 1/2 |
|||
|
2 |
60.3 |
2.375 |
3/4 |
3 |
|
1 |
3 |
|||
|
1 1/4 |
3 |
|||
|
1 1/2 |
3 |
|||
|
2 1/2 |
73.0 |
2.875 |
1 |
3 1/2 |
|
1 1/4 |
3 1/2 |
|||
|
1 1/2 |
3 1/2 |
|||
|
2 |
3 1/2 |
|||
|
3 |
88.9 |
3.500 |
1 |
3 1/2 |
|
1 1/2 |
3 1/2 |
|||
|
2 |
3 1/2 |
|||
|
2 1/2 |
3 1/2 |
|||
|
3 1/2 |
101.6 |
4.000 |
1 1/4 |
4 |
|
1 1/2 |
4 |
|||
|
2 |
4 |
|||
|
2 1/2 |
4 |
|||
|
3 |
4 |
|||
|
4 |
114.3 |
4.500 |
1 1/2 |
4 |
|
2 |
4 |
|||
|
2 1/2 |
4 |
|||
|
3 |
4 |
|||
|
3 1/2 |
4 |
|||
|
5 |
141.3 |
5.563 |
2 |
5 |
|
2 1/2 |
5 |
|||
|
3 |
5 |
|||
|
3 1/2 |
5 |
|||
|
4 |
5 |
|||
|
6 |
168.3 |
6.625 |
2 1/2 |
5 1/2 |
|
3 |
5 1/2 |
|||
|
3 1/2 |
5 1/2 |
|||
|
4 |
5 1/2 |
|||
|
5 |
5 1/2 |
|||
|
8 |
219.1 |
8.625 |
3 |
6 |
|
3 1/2 |
6 |
|||
|
4 |
6 |
|||
|
5 |
6 |
|||
|
6 |
6 |
|||
|
10 |
273.1 |
10.750 |
4 |
7 |
|
5 |
7 |
|||
|
6 |
7 |
|||
|
8 |
7 |
|||
|
12 |
323.9 |
12.750 |
5 |
8 |
|
6 |
8 |
|||
|
8 |
8 |
|||
|
10 |
8 |
|||
| Product range and theoretical weights (kg) | |||||||||
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
These pipe fittings find extensive use across industries like power generation, petrochemical, oil and gas, chemical processing, and shipbuilding. In power plants, they play a crucial role in boilers, steam lines, and heat exchangers. The petrochemical sector relies on them for transporting hot gases and fluids under pressure. Refineries and offshore platforms depend on these fittings for critical high-temperature service lines. Their versatility, combined with excellent weldability and robust mechanical properties, makes Carbon Steel P235GH Pipe Fittings a trusted choice for industrial applications that demand durability and heat resistance.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
