Machuca Fittings stands out as a top manufacturer and supplier of Stainless Steel 202 Pipe Fittings in Kuala Lumpur, Malaysia. They’re well-known for providing high-performance products that meet global quality standards. Thanks to their state-of-the-art production facilities and rigorous quality checks, every fitting is crafted with precision, ensuring durability, strength, and wear resistance. Stainless Steel 202 Pipe Fittings are favored for their cost-effectiveness and reliable performance across various environments. Serving sectors like construction, petrochemical, food processing, and marine, Machuca Fittings has earned a solid reputation as a trusted partner for dependable piping solutions around the globe.
| Specifications | : | ASTM A403 / ASME SA403 |
| Dimensions | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Size | : | 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated) |
| Thickness | : | SCH 5S, SCH 10S, SCH 20S, SCH 40S, SCH 80S, SCH 120S, SCH 1605, SCH XXS |
| Type | : | Seamless / Welded / Fabricated |
These fittings are made from a blend of iron, 16–18% chromium, 4–6% nickel, and 7.5–10% manganese, along with small amounts of nitrogen, silicon, and carbon. The higher manganese content boosts strength while minimizing nickel usage, making them a more economical choice compared to higher-grade options. In terms of mechanics, they boast a tensile strength of about 515 MPa, a yield strength of around 275 MPa, and good elongation properties. They also show excellent toughness, wear resistance, and moderate corrosion resistance, making them ideal for situations that demand high strength, durability, and affordability in structural and industrial applications.
| Grade 202 | C | Mn | Si | P | S | Cr | Ni | N |
| max. | 0.15 | 7.50-10 | 1 | 0.060 | 0.030 | 17- 19 | 4-6 | 0.25 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min |
| 202 | 515 | 275 | 40 |
Machuca Fittings one of the largest suppliers of Stainless Steel 202 Pipe Fittings in Kuala lumpur, Malaysia. We specialize in providing a wide range of high-quality, durable fittings for various industrial applications. Our inventory includes elbows, tees, reducers, couplings, and other essential fittings designed to offer exceptional corrosion resistance and strength. Stainless Steel 202 is known for its cost-effectiveness and excellent mechanical properties, making it ideal for industries such as construction, chemical processing, and food processing. With a commitment to customer satisfaction, timely delivery, and competitive pricing, we are the trusted choice for Stainless Steel 202 Pipe Fittings in the Malaysia.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 202 Pipe Fittings from Machuca Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| STANDARD | UNS | WERKSTOFF NR. |
| SS 202 | S20200 | 1.4373 |
Stainless steel 202 pipe fittings enhance corrosion resistance, making it suitable for slightly corroded environments. They provide high strength and durability, providing long life even under high stress and temperature conditions. Their lightweight nature makes them easier to handle and install compared to other stainless steel products. The SS 202 fittings are cost-effective, providing performance at an affordable price. They also exhibit excellent weldability and machinability, facilitating fabrication. With their sleek finish, these inserts are ideal for decor and retain their shine over time, requiring minimal maintenance.
| Element | Density, lb/in3 | Modulus of Elasticity, psi | Linear Expansion, 68-212°F, /°F | Thermal Conductivity, Btu/ft hr°F | Heat Capacity, Btu/lb°F | Electrical Resistivity, Ω-inch |
| SS 202 | 0.285 | 29 x 106 | 9.4 x 10-6 | 8.7 | 0.12 | 27.6 x 10-6 |
| Nominal Pipe Size | Outside Diameter | 90° Elbows | 45° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
|
(inches) |
Long Radius |
Short Radius |
Long Radius |
Long Radius |
||||
|
(mm) |
(inches) |
Center to Face
(inches) |
Center to Face
(inches) |
Center to Face
(inches) |
Radius
(inches) |
Center to Center
(inches) |
Back to face
(inches) |
|
|
1/2 |
21.3 |
0.840 |
1 1/2 |
– |
5/8 |
2 |
1 7/8 |
|
|
3/4 |
26.7 |
1.050 |
1 1/8 |
– |
7/16 |
2 1/4 |
1 11/16 |
|
|
1 |
33.4 |
1.315 |
1 1/2 |
1 |
7/8 |
3 |
2 3/16 |
|
|
1 1/4 |
42.2 |
1.660 |
1 7/8 |
1 1/4 |
1 |
3 3/4 |
2 3/4 |
|
|
1 1/2 |
48.3 |
1.900 |
2 1/4 |
1 1/2 |
1 1/8 |
3 |
4 1/2 |
3 1/4 |
|
2 |
60.3 |
2.375 |
3 |
2 |
1 3/8 |
4 |
6 |
4 3/16 |
|
2 1/2 |
73.0 |
2.875 |
3 3/4 |
2 1/2 |
1 3/4 |
5 |
7 1/2 |
5 3/16 |
|
3 |
88.9 |
3.500 |
4 1/2 |
3 |
2 |
6 |
9 |
6 1/4 |
|
3 1/2 |
101.6 |
4.000 |
5 1/4 |
3 1/2 |
2 1/4 |
7 |
10 1/2 |
7 1/4 |
|
4 |
114.3 |
4.500 |
6 |
4 |
2 1/2 |
8 |
12 |
8 1/4 |
|
5 |
141.3 |
5.563 |
7 1/2 |
5 |
3 1/8 |
10 |
15 |
10 5/16 |
|
6 |
168.3 |
6.625 |
9 |
6 |
3 3/4 |
12 |
18 |
12 5/16 |
|
8 |
219.1 |
8.625 |
12 |
8 |
5 |
12 |
24 |
16 5/16 |
|
10 |
273.1 |
10.750 |
15 |
10 |
6 1/4 |
15 |
30 |
20 3/8 |
|
12 |
323.9 |
12.750 |
18 |
12 |
7 1/2 |
18 |
36 |
24 3/8 |
Yes, custom sizes are available for Stainless Steel 202 Pipe Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@machucafittings.com.
Stainless Steel 202 Pipe Fittings are widely utilized across various industries due to their durability and cost-effectiveness. In construction, they’re used for architectural frameworks, railings, and structural piping because of their strength and versatility. The food processing and kitchen equipment sectors appreciate them for their hygienic and easy-to-clean piping systems. They also find applications in light-duty petrochemical operations, water treatment systems, and textile machinery. Furthermore, they’re suitable for moderately corrosive environments in marine and transport industries. With their perfect blend of performance and affordability, Stainless Steel 202 Pipe Fittings offer versatile solutions for many needs.
