Machuca Fittings is a trusted manufacturer and supplier of Stainless Steel 321 Pipe Fittings based in Kuala Lumpur, Malaysia. They pride themselves on delivering top-notch products that meet the needs of industries where durability and precision are key. By utilizing cutting-edge manufacturing techniques and adhering to international standards, the company produces fittings that are built to endure tough conditions. Known for their outstanding corrosion resistance, strength, and stability at high temperatures, Stainless Steel 321 Pipe Fittings are a go-to choice for sectors like oil, gas, petrochemical, marine, and power generation. Machuca Fittings is committed to providing reliable performance, timely deliveries, and ensuring customer satisfaction in markets around the world.
| Specifications | ASTM A403 / ASME SA403 |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Size Range | 15 NB UP TO 1200 NB ; 1/8″ NB TO 48″ NB |
| Schedule | SCH 5S , 10S ,10, 20 , 40S , 40 , STD , 60 , 80S , 80 , XS , 100 , 120 , 140 , 160 & XXS. |
| Type | Seamless & 100% X-Ray Welded, Fabricated |
These fittings are stabilized with titanium and contain 17–19% chromium, 9–12% nickel, along with trace amounts of carbon, manganese, silicon, and phosphorus. The inclusion of titanium significantly boosts their resistance to intergranular corrosion, especially after being exposed to high temperatures. They boast a tensile strength of about 515 MPa and a yield strength of 205 MPa, along with impressive creep and stress rupture characteristics. Even in high-temperature environments, these fittings maintain excellent toughness, offering remarkable durability, oxidation resistance, and mechanical performance in critical conditions.
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 5(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Machuca Fittings one of the largest suppliers of Stainless Steel 321 Pipe Fittings in Kuala lumpur, Malaysia. We specialize in providing a wide range of high-quality, durable fittings for various industrial applications. Our inventory includes elbows, tees, reducers, couplings, and other essential fittings designed to offer exceptional corrosion resistance and strength. Stainless Steel 321 is known for its cost-effectiveness and excellent mechanical properties, making it ideal for industries such as construction, chemical processing, and food processing. With a commitment to customer satisfaction, timely delivery, and competitive pricing, we are the trusted choice for Stainless Steel 321 Pipe Fittings in the Malaysia.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 321 Pipe Fittings from Machuca Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
| Grade | Specific Heat 0-100°C (J/kg.K) | Mean Co-eff of Thermal Expansion (µm/m/°C) | Elastic Modulus (GPa) | Thermal Conductivity (W/m.K) | Density (kg/m3) | Elec Resistivity (nΩ.m) | |||
| 0-315°C | 0-100°C | 0-538°C | At 500°C | At 100°C | |||||
| Stainless Steel 321 | 500 | 17.2 | 16.6 | 18.6 | 193 | 22.2 | 16.1 | 8027 | 720 |
Stainless steel 321 pipe fittings offer many advantages, including excellent resistance to high temperature oxidation and corrosion, making them ideal for use in hot environments and chemically reactive Titanium inclusions prevents carbide precipitation, enhances weldability and maintains high thermal properties. These fittings provide superior mechanical properties such as high tensile strength, rigidity and durability. They are highly resistant to intergranular corrosion, making them suitable for pressure molds, heat exchangers, and chemical applications Overall, stainless steel 321 ensures durability and mechanical reliability in the circumstances.
Yes, custom sizes are available for Stainless Steel 321 Pipe Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@machucafittings.com.
| Nominal Pipe Size | Inch | 3/4 | 1 1/4 | 2 | 3 | 4 | 6 | 10 | 12 | |
|---|---|---|---|---|---|---|---|---|---|---|
| OD. | Inch | 1.05 | 1.66 | 2.375 | 3.5 | 4.5 | 6.625 | 10.75 | 12.75 | |
| Millimeter | 26.7 | 42.2 | 60.3 | 88.9 | 114.3 | 168.3 | 273.1 | 323.9 | ||
| Straight Crosses | Center to End | Inch | 1 7/8 | 2 1/2 | 3 3/8 | 4 1/8 | 5 5/8 | 8 1/2 | 10 | |
| Caps | L. | Inch | 1 | 1 1/2 | 1 1/2 | 2 | 2 1/2 | 3 1/2 | 5 | 6 |
| Stub Ends | Long L. | Inch | 3 | 4 | 6 | 6 | 6 | 8 | 10 | 10 |
| Lap Diameter | Inch | 1 11/16 | 2 1/2 | 3 5/8 | 5 | 6 3/16 | 8 1/2 | 12 3/4 | 15 | |
| Short L. | Inch | 2 | 2 | 2 1/2 | 2 1/2 | 3 | 3 1/2 | 5 | 6 | |
| Straight Tees | Center to End | Inch | 1 1/8 | 1 7/8 | 2 1/2 | 3 3/8 | 4 1/8 | 5 5/8 | 8 1/2 | 10 |
| Nominal Pipe Size | Outside Diameter | 90° Elbows | 45° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
(inches) | Long Radius | Short Radius | Long Radius | Long Radius | ||||
(mm) | (inches) | Center to Face (inches) | Center to Face (inches) | Center to Face (inches) | Radius (inches) | Center to Center (inches) | Back to face (inches) | |
1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
3/4 | 26.7 | 1.050 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
Stainless Steel 321 Pipe Fittings are extensively utilized in industries that demand exceptional strength and corrosion resistance at elevated temperatures. They are perfect for petrochemical and chemical processing plants, heat exchangers, and furnace components where scaling and oxidation resistance is crucial. In the power generation sector, they find applications in superheaters and boiler systems. The aerospace industry incorporates them into jet engine parts, while the marine sector benefits from their resilience against corrosive seawater. Additionally, the food processing and pharmaceutical industries rely on these fittings for hygienic applications. With their dependable performance and long-lasting nature, they are a smart choice for a variety of demanding environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
